7450G75.05A600
2820.004 IGNITION CONTROL
Item | Part number | Description |
---|---|---|
1 | 8093091 | GAS ENGINE CARBURETTOR |
2 | 83991490 | GEAR |
3 | 8093128 | WASHER |
4 | 8093129 | NUT |
5 | 83416201 | O-RING |
6 | 82855493 | SCREW |
7 | 8099142 | WASHER |
8 | 8093040 | WASHER |
9 | 8093038 | DRIVE BEARING |
10 | 8093084 | SHAFT |
11 | 8093073 | KEY |
12 | 8093039 | WASHER |
13 | 8093063 | DRIVE BEARING |
14 | 8093085 | SPACING BAR |
15 | 8093086 | IGNITION CONTROL DISC |
16 | 8093047 | PICK-UP |
17 | 8093042 | PIN |
19 | 8093087 | COVER |
20 | 8093023 | SCREW |
21 | 8093024 | WASHER |
22 | 8093019 | WASHER |
23 | 8093013 | SCREW |
