| Item |
Part number |
Description |
|
1 |
8018538 |
WATER RADIATOR ASSY |
|
2 |
8024214 |
WATER RADIATOR ASSY |
|
2 |
8014291 |
WATER PIPE |
|
3 |
4936741 |
CLIP |
|
4 |
8813238 |
WATER HOSE |
|
5 |
8102099 |
RUBBER SLEEVE |
|
6 |
17742687 |
RUBBER SLEEVE |
|
7 |
17764791 |
CLIP Ø32/50 MM |
|
8 |
17764891 |
CLIP Ø40/60 MM |
|
9 |
16605524 |
HEXAGON BOLT M8X20 MM |
|
10 |
17089774 |
SPRING WASHER Ø8,4X22 MM SP=2,4 MM |
|
11 |
8014963 |
WATER PIPE |
|
12 |
16992111 |
THREADED PLUG M10X1 |
|
13 |
4858606 |
GASKET Ø10X14X1 MM |
|
14 |
8020887 |
SUPPORT LEFT |
|
15 |
8020885 |
SUPPORT RIGHT |
|
16 |
8014303 |
TIE ROD LEFT |
|
17 |
8014304 |
TIE ROD RIGHT |
|
18 |
8090413 |
KIT-RADIATOR A.S. COMPLETE |
|
19 |
8090341 |
KIT-RADIATOR A.S. COMPLETE |
|
20 |
17038421 |
HEXAGON NUT M12 (8) |
|
21 |
17091074 |
WASHER Ø12X24X2,8 MM |
|
22 |
16614824 |
SCREW M16X50 |
|
23 |
17092174 |
SPRING WASHER Ø16X32X3,4 |
|
24 |
17038921 |
NUT M16X2 |
|
25 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
|
26 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
27 |
17037931 |
HEXAGON NUT M8X1,25 |
|
28 |
4935488 |
RADIATOR PLUG |
|
29 |
15541521 |
SCREW M12X1.25X90 [up to 565948] |
|
30 |
8020833 |
SPACING BAR |
