7675G75.05A600
2820.005 IGNITION CONTROL
| Item |
Part number |
Description |
|
1 |
8093091 |
GAS ENGINE CARBURETTOR |
|
2 |
83991490 |
GEAR |
|
3 |
8093128 |
WASHER |
|
4 |
8093129 |
NUT |
|
5 |
83416201 |
O-RING |
|
6 |
82855493 |
SCREW |
|
7 |
8099142 |
WASHER |
|
8 |
8093040 |
WASHER |
|
9 |
8093038 |
DRIVE BEARING |
|
10 |
8093084 |
SHAFT |
|
11 |
8093073 |
KEY |
|
12 |
8093039 |
WASHER |
|
13 |
8093063 |
DRIVE BEARING |
|
14 |
8093085 |
SPACING BAR |
|
15 |
8093086 |
IGNITION CONTROL DISC |
|
16 |
8093047 |
PICK-UP |
|
17 |
8093042 |
PIN |
|
18 |
8093069 |
IGNITION CONTROL DISC |
|
19 |
8093087 |
COVER |
|
20 |
8093023 |
SCREW |
|
21 |
8093024 |
WASHER |
|
22 |
8093019 |
WASHER |
|
23 |
8093013 |
SCREW |
