8035U00.01
A05050003 INTAKE MANIFOLD - front inlet upward
| Item | Part number | Description |
|---|---|---|
| 1 | 4602345 | INTAKE ELBOW |
| 2 | 4851921 | INTAKE ELBOW GASK. |
| 3 | 98400791 | INTAKE ELBOW GASK. |
| 4 | 4577310 | THREADED PLUG |
| 5 | 4930712 | SPACING BAR |
| 6 | 11234721 | HEXAGON BOLT M10X1,25X45 MM |
| 7 | 11193879 | SPRING WASHER Ø8X16 MM |
