Item |
Part number |
Description |
1 |
8029265 |
RETAINER [from 10-99] |
2 |
8028986 |
RETAINER [up to 10-99] |
3 |
8018971 |
ENGINE ACTUATOR ASSY |
4 |
8101556 |
SPACING BAR SP=13,00 MM |
5 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
6 |
17037931 |
HEXAGON NUT M8X1,25 |
7 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
8 |
15970921 |
HEXAGON BOLT M10X1,25X35 MM |
9 |
16603824 |
SCREW M6X25 |
10 |
17094714 |
WASHER Ø6,4X12 MM |
11 |
4934541 |
BRACE/STRUT |
12 |
17037821 |
HEXAGON NUT M6X1 |
13 |
8823237 |
TIE ROD |
14 |
17152721 |
NUT M6 |
15 |
17088474 |
WASHER Ø6X12 MM |
16 |
8018673 |
PICK-UP |
17 |
8024920 |
RETAINER |
18 |
16603624 |
HEXAGON BOLT M6X16 MM (8.8) |
19 |
8018968 |
ENGINE HARNESS |
20 |
8031536 |
LEVER |
