| Item |
Part number |
Description |
|
1 |
10519601 |
WASHER Ø8X17 MM |
|
2 |
98481924 |
SUPPORT [from 672797] |
|
3 |
4928337 |
PIPE SOCKET |
|
4 |
16729624 |
STUD M8X35 |
|
5 |
8109801 |
OIL/WATER HEAT EXCHANGER ASSY |
|
6 |
11198379 |
SPRING WASHER Ø10X20 MM SP=2,6 |
|
7 |
17094914 |
WASHER 8x16 |
|
8 |
4858606 |
GASKET Ø10X14X1 MM |
|
9 |
16992140 |
PLUG M10X1 |
|
10 |
14328501 |
LOCK PLUG Ø16 MM |
|
11 |
17282081 |
O-RING Ø20,2 MM SP=2,62 MM |
|
12 |
14457581 |
O-RING Ø20,29 MM SP=2,62 MM |
|
13 |
16729324 |
STUD M8X12X20 MM |
|
14 |
16604924 |
SCREW |
|
16 |
15888721 |
HEXAGON BOLT M10X1,25X55 MM |
|
17 |
17037931 |
HEXAGON NUT M8X1,25 |
|
18 |
4929576 |
PIPE SOCKET |
|
19 |
16992240 |
THREADED PLUG M12X1,5 |
|
20 |
4858607 |
WASHER Ø12X17 MM SP=1,5 MM |
|
24 |
16736024 |
STUD M14X70 |
