| Item |
Part number |
Description |
|
1 |
8015293 |
MARINE GEAR 3,118:1 |
|
2 |
8006087 |
WATER PIPE |
|
3 |
4934782 |
COUPLING BELL |
|
4 |
8005350 |
FLEXPLATE |
|
5 |
13547521 |
STUD |
|
6 |
11198379 |
SPRING WASHER Ø10X20 MM SP=2,6 |
|
7 |
12164711 |
HEXAGON NUT M10X1,25 |
|
8 |
15970921 |
HEXAGON BOLT M10X1,25X35 MM |
|
9 |
15970521 |
HEXAGON BOLT M10X20 MM |
|
10 |
10571879 |
WASHER |
|
11 |
8016304 |
OIL/WATER HEAT EXCHANGER ASSY |
|
12 |
8102099 |
RUBBER SLEEVE |
|
13 |
17764793 |
CLIP Ø32/50 MM |
|
14 |
5116798 |
CLIP ASSY [from 06-93] |
|
15 |
4935465 |
PIPE SOCKET |
|
16 |
8101073 |
PIPE SOCKET |
|
17 |
8100724 |
HOSE |
|
18 |
4935780 |
OIL HOSE |
|
19 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
|
20 |
4936740 |
SUPPORT |
|
21 |
16605734 |
HEXAGON BOLT M8X30 MM |
|
22 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
23 |
8107188 |
WATER PIPE |
|
24 |
8107189 |
WATER PIPE |
|
25 |
17742887 |
RUBBER SLEEVE |
|
26 |
17742687 |
RUBBER SLEEVE |
|
27 |
17737687 |
WATER HOSE |
|
29 |
17764593 |
CLIP Ø20/32 MM |
|
30 |
8110499 |
RETAINER |
|
31 |
4936741 |
CLIP |
|
32 |
16609824 |
HEXAGON BOLT M12X1,75X25 MM |
|
33 |
17091074 |
WASHER Ø12X24X2,8 MM |
|
34 |
17089774 |
SPRING WASHER Ø8,4X22 MM SP=2,4 MM |
|
35 |
17037931 |
HEXAGON NUT M8X1,25 |
|
36 |
8109067 |
RETAINER |
|
37 |
4936277 |
CLIP [up to 03-97] |
|
38 |
16605424 |
SCREW M8X16 MM (8.8) |
