| Item |
Part number |
Description |
|
1 |
8015446 |
AIR CLEANER ASSY |
|
5 |
4936137 |
CHOCKED FILTER INDIC. MECHANICAL |
|
6 |
8014635 |
SUPPORT |
|
7 |
8104719 |
SPACING BAR |
|
8 |
8015453 |
SPACING BAR |
|
9 |
16729524 |
STUD M8X1,25X30 |
|
10 |
17037931 |
HEXAGON NUT M8X1,25 |
|
11 |
17089774 |
SPRING WASHER Ø8,4X22 MM SP=2,4 MM |
|
12 |
16731524 |
STUD M8X40 MM |
|
13 |
17038121 |
HEXAGON NUT M10 |
|
14 |
17090474 |
SPRING WASHER Ø10X27 MM SP=2,5 |
|
15 |
16605524 |
HEXAGON BOLT M8X20 MM |
|
17 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
18 |
8014681 |
FILTER HOSE |
|
19 |
17765391 |
CLIP Ø90/110 MM |
|
20 |
17765091 |
CLIP Ø60/80 MM |
|
21 |
8104685 |
AIR PIPE/DUCT |
|
22 |
17745687 |
RUBBER SLEEVE |
|
23 |
17738187 |
WATER HOSE |
|
24 |
17764592 |
CLIP Ø20/32 MM |
|
25 |
8014686 |
AIR PIPE/DUCT |
|
26 |
8111710 |
CLIP |
|
27 |
98421371 |
AIR HOSE |
|
31 |
8009967 |
NUT |
|
32 |
98416134 |
WASHER [from 555940] |
|
33 |
8022540 |
CHOCKED FILTER INDIC. MECHANICAL |
