| Item |
Part number |
Description |
|
1 |
8015893 |
MARINE GEAR 1,51:1 |
|
2 |
8018591 |
SUPPORT [from 05-94] |
|
3 |
8012407 |
COUPLING BELL |
|
4 |
8113696 |
FLEXIBLE COUPLING |
|
5 |
8016304 |
OIL/WATER HEAT EXCHANGER ASSY |
|
6 |
5116798 |
CLIP ASSY [from 06-93] |
|
7 |
17494934 |
WASHER Ø10X18,1X2,2 MM |
|
8 |
4935779 |
HOSE |
|
9 |
4935465 |
PIPE SOCKET |
|
10 |
8105620 |
HOSE |
|
11 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
12 |
13449721 |
STUD M10X15X30 |
|
13 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
|
14 |
17038221 |
HEXAGON NUT M10 |
|
15 |
16606024 |
SCREW M8X45 MM |
|
16 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
17 |
15970521 |
HEXAGON BOLT M10X20 MM |
|
18 |
13449521 |
STUD M10X15X25 |
