| Item |
Part number |
Description |
|
1 |
4815431 |
TANK FOR PREHEATER |
|
2 |
8007323 |
ELECTROVALVE |
|
3 |
4858605 |
WASHER Ø8X12 MM |
|
4 |
4858607 |
WASHER Ø12X17 MM SP=1,5 MM |
|
5 |
4864082 |
BANJO BOLT M12X1,5X25 MM |
|
6 |
18088092 |
CLIP |
|
7 |
17724387 |
HOSE |
|
8 |
98416591 |
SWIVEL COUPLING |
|
9 |
18088192 |
CLIP m10-16 |
|
10 |
4864078 |
BANJO BOLT M8X1,25 |
|
11 |
4551099 |
SWIVEL COUPLING |
|
12 |
4732530 |
SUPPORT |
|
13 |
17798074 |
WASHER Ø5X9,2X1 MM |
|
14 |
10389911 |
CYLIND-HEAD SCREW M5X25 MM |
|
15 |
11902011 |
PLUG M8 |
|
16 |
4551101 |
SCREW CONNECTOR |
|
17 |
8018732 |
HEATER PLUG |
|
18 |
4557649 |
WASHER |
|
19 |
17724587 |
RUBBER HOSE Ø7,5X14,5 MM |
|
20 |
16550660 |
WASHER Ø8 MM |
|
22 |
4617262 |
SPACING BAR |
|
23 |
4023905 |
DOWEL |
|
24 |
4023904 |
CAP |
|
25 |
17037931 |
HEXAGON NUT M8X1,25 |
|
26 |
17094914 |
WASHER 8x16 |
|
27 |
16605734 |
HEXAGON BOLT M8X30 MM |
|
28 |
17089471 |
SPRING WASHER Ø16X8 MM SP=1,4 MM |
