Catalogue Menu
8045SE00.00A801
0710.109 INTAKE MANIFOLD
| Item | Part number | Description |
|---|---|---|
| 1 | 500336679 | INTAKE ELBOW |
| 2 | 4851921 | INTAKE ELBOW GASK. |
| 3 | 4577310 | THREADED PLUG |
| 4 | 4858606 | GASKET Ø10X14X1 MM |
| 5 | 16992111 | THREADED PLUG M10X1 |
| 6 | 17094914 | WASHER 8x16 |
| 7 | 13449524 | STUD M10X1,25X15X25 |
| 8 | 13449321 | STUD M10X1,25X15X20 MM |
| 9 | 16605824 | HEXAGON BOLT M8X35 MM |
| 10 | 16508460 | WASHER 22x27x1,5 |
| 11 | 4663081 | PIPE SOCKET |
| 12 | 16605924 | SCREW M8X40 MM |
