8045SE00.50
A01050023/02 OIL SUMP - max longitudinal inclination 45°

Iveco/FPT OIL SUMP

Item Part number Description
1 500330791 COVER
2 98417986 FLAT ENGINE GASKET
3 4806862 FLYWHEEL HOUSING ASSY
4 99457401 SHAFT SEAL CORCOS
5 4718740 PLUG
6 17275510 DOWEL PIN Ø10 MM
7 17089474 SPRING WASHER Ø8X16 MM SP=1,4 MM
8 4607466 CONNECTING PLATE
9 16998011 PLUG M35X1,5
10 98489586 REAR C.CASE COVER
11 17289281 O-RING Ø34,5 MM SP=3,53 MM
12 16043521 SCREW M8X22
13 16605424 SCREW M8X16 MM (8.8)
14 4849994 FLAT ENGINE GASKET
15 16605824 HEXAGON BOLT M8X35 MM
16 17094914 WASHER 8x16
