8060SM21.10
0710.132 INTAKE MANIFOLD
Item | Part number | Description |
---|---|---|
1 | 4819949 | INTAKE ELBOW |
2 | 4851921 | INTAKE ELBOW GASK. |
3 | 16729424 | STUD M8X1,25X25 |
4 | 16729624 | STUD M8X35 |
5 | 10260160 | SEAL GASKET Ø10X14 MM SP=1 MM |
6 | 10300240 | PLUG M6 |
7 | 10297760 | SEAL GASKET Ø6,2 MM |
10 | 11903140 | PLUG M10X1,25 |
11 | 17037931 | HEXAGON NUT M8X1,25 |
12 | 11194074 | WASHER Ø8,4 MM |
