| Item |
Part number |
Description |
|
1 |
500372866 |
COVER |
|
2 |
500318720 |
FLAT ENGINE GASKET Ø50 MM |
|
3 |
4605220 |
OIL NOZZLE |
|
4 |
99469265 |
SHAFT SEAL CORCOS |
|
5 |
500373219 |
FRONT C.CASE COVER ASSY |
|
6 |
500321670 |
TIMINGGEAR HOUSIN ASSY REAR |
|
7 |
98424045 |
FLAT ENGINE GASKET |
|
8 |
98424046 |
FLAT ENGINE GASKET |
|
9 |
16746824 |
STUD M8X30 MM (8.8) |
|
10 |
17094904 |
WASHER Ø8X16X1,6 MM |
|
11 |
17275410 |
DOWEL PIN Ø8 MM |
|
12 |
16603824 |
SCREW M6X25 |
|
13 |
17037931 |
HEXAGON NUT M8X1,25 |
|
14 |
17088574 |
WASHER Ø6X12 MM |
|
15 |
4848314 |
HEXAGON BOLT L=110 MM |
|
16 |
4848315 |
HEXAGON BOLT L=79 MM |
|
17 |
16729324 |
STUD M8X12X20 MM |
|
18 |
16044924 |
SCREW M8X1,25X85 MM |
|
19 |
16605724 |
SCREW M8X1,25X30 |
|
20 |
16043524 |
SCREW M8X22 MM |
|
21 |
16606124 |
HEXAGON BOLT M8X50 MM |
|
22 |
16605824 |
HEXAGON BOLT M8X35 MM |
|
23 |
13526170 |
THREADED INSERT M10X1,25X20 MM |
|
25 |
16606524 |
HEXAGON BOLT M8X70 MM |
|
26 |
98489586 |
REAR C.CASE COVER |
|
28 |
4849994 |
FLAT ENGINE GASKET |
|
29 |
4860432 |
RING |
|
30 |
4861291 |
TRANSMITTER |
|
31 |
4843857 |
SUPPORT |
|
32 |
4854020 |
SUPPORT |
|
33 |
99457401 |
SHAFT SEAL CORCOS |
|
37 |
11306924 |
HEXAGON BOLT M10X1,25X30 MM |
|
38 |
17095125 |
WASHER |
|
39 |
16603624 |
HEXAGON BOLT M6X16 MM (8.8) |
|
40 |
17088471 |
SPRING WASHER Ø6X12 MM SP=1,2 MM |
