Item |
Part number |
Description |
1 |
93436521 |
AIR MANIFOLD |
2 |
99436925 |
FLAT ENGINE GASKET Ø50 MM |
3 |
11343724 |
HEXAGON BOLT M10X70 MM |
4 |
15971824 |
SCREW M10X1,25X100 |
5 |
17095101 |
WASHER Ø10X18 MM |
6 |
4843473 |
AIR PIPE/DUCT |
7 |
17283481 |
O-RING Ø42,5 MM SP=2,6 MM |
8 |
98417936 |
MANIFOLD |
9 |
98490833 |
HEXAGON BOLT M8X1,25X30 MM |
10 |
98428400 |
FLAT ENGINE GASKET |
11 |
98415215 |
WASHER Ø10X20X2,3 MM |
12 |
17037931 |
HEXAGON NUT M8X1,25 |
13 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
14 |
4834605 |
RETAINER |
15 |
16605524 |
HEXAGON BOLT M8X20 MM |
16 |
17089771 |
WASHER Ø8X22X1,5 MM |
17 |
98413688 |
RETAINER |
18 |
16043521 |
SCREW M8X22 |
19 |
98413687 |
RETAINER |
21 |
4843862 |
CLIP Ø50/70 MM |
22 |
10265160 |
SEAL GASKET Ø35,3 MM |
23 |
10276711 |
THREADED PLUG M35 |
