| Item |
Part number |
Description |
|
1 |
8856938 |
PARALLEL ROLLER |
|
2 |
8859307 |
BUSH |
|
3 |
8859309 |
SET OF SHIMS KIT |
|
4 |
8859314 |
SPLITTER GEAR 4TH SPEED |
|
6 |
8859375 |
NUT |
|
10 |
8859831 |
REVERSE GEAR REVERSE |
|
11 |
8859832 |
REVERSE GEAR REVERSE |
|
12 |
8860343 |
STOP WASHER |
|
13 |
8860354 |
CONTROL PISTON |
|
15 |
8860357 |
SPRING |
|
16 |
8860774 |
SHIM KIT |
|
17 |
8860775 |
REVERSE GEAR |
|
18 |
8860777 |
SET OF SHIMS KIT |
|
21 |
8861569 |
RETURN SHAFT REVERSE |
|
22 |
8861580 |
SYNCHRONIZER |
|
23 |
8861581 |
SYNCHRONIZER |
|
25 |
8861596 |
RING |
|
32 |
8861961 |
KIT-SYNCHRONIZER |
|
34 |
8861966 |
SPLITTER GEAR 3RD SPEED |
|
35 |
8861967 |
SPLITTER GEAR 2ND SPEED |
|
36 |
8861968 |
SPLITTER GEAR 1ST SPEED |
|
38 |
8862587 |
STOP WASHER |
|
39 |
8862589 |
SPACING BAR |
|
42 |
8863138 |
FASTENING RING |
|
43 |
8863189 |
INPUT SHAFT INPUT [up to 06-04-97] |
|
44 |
17259070 |
DOWEL PIN |
|
45 |
99808072 |
COUNTERSHAFT ASSY |
|
46 |
1905241 |
ROLLER CAGE Ø74X66 MM SP=36 MM |
|
48 |
1905250 |
GEARBOX BEARINGS Ø60X110 MM SP=22 MM [up to 13M93] |
|
49 |
1905252 |
GEARBOX BEARINGS Ø40X75 MM SP=26 MM |
|
50 |
1905253 |
ROLLER CAGE Ø60X68 MM SP=34 MM |
|
51 |
1905254 |
ROLLER CAGE Ø60X68 MM SP=34 MM |
|
52 |
1905260 |
DRIVE BEARING Ø50X110X27 MM |
|
53 |
1905270 |
ROLLER CAGE Ø30X48 MM SP=31 MM |
|
54 |
8863330 |
SYNCHRONIZER [up to 17M93] |
|
55 |
8863331 |
SYNCHRONIZER [up to 17M93] |
|
56 |
8860415 |
SYNCHRONIZER |
|
58 |
8859306 |
MAIN SHAFT MAIN |
|
59 |
8859352 |
PLUG |
|
60 |
8867446 |
SYNCHRONIZER |
|
61 |
8867447 |
SYNCHRONIZER 4TH SPEED |
|
62 |
99431569 |
GEARBOX BEARINGS Ø60X110 MM SP=22 MM |
|
63 |
1905242 |
ROLLER CAGE Ø53X46 MM SP=36 MM |
|
64 |
1905490 |
GEARBOX BEARINGS Ø60X110 MM SP=22 MM |
|
65 |
8868351 |
INPUT SHAFT INPUT [from 07-04-97] |
|
66 |
8868335 |
SET OF SHIMS SP=2,4-2,8 MM [from 07-04-97] |
|
67 |
16868373 |
CIRCLIP |
|
70 |
8861673 |
SLIDING SLEEVE |
|
71 |
8861677 |
GEAR BOX HUB |
|
80 |
8861848 |
SLIDING SLEEVE |
|
81 |
8860334 |
GEAR BOX HUB |
|
83 |
8859880 |
SYNCHRONIZER |
