| Item |
Part number |
Description |
|
1 |
8029751 |
WATER PIPE |
|
2 |
8102099 |
RUBBER SLEEVE |
|
3 |
17764793 |
CLIP Ø32/50 MM |
|
4 |
8020637 |
RUBBER SLEEVE |
|
5 |
8018455 |
WATER HOSE |
|
6 |
4936741 |
CLIP |
|
7 |
4917793 |
PLUG M18 |
|
8 |
4858610 |
WASHER Ø18X24 MM SP=1,5 MM |
|
9 |
8100546 |
RUBBER SLEEVE |
|
10 |
8105277 |
SACRIFICAL ANODE Ø14 MM |
|
11 |
8813238 |
WATER HOSE |
|
12 |
8017130 |
WATER PIPE |
|
13 |
8008755 |
FLAT ENGINE GASKET |
|
14 |
17090074 |
SPRING WASHER Ø10X20X1,9 MM |
|
15 |
17742687 |
RUBBER SLEEVE |
|
16 |
11306921 |
SCREW M10X1,25X30 |
|
17 |
8030431 |
RETAINER |
|
18 |
17037931 |
HEXAGON NUT M8X1,25 |
|
19 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
20 |
17764893 |
CLIP Ø40/60 MM |
|
21 |
15970421 |
HEXAGON BOLT M10X18 MM |
|
22 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
23 |
17038221 |
HEXAGON NUT M10 |
|
24 |
17095304 |
WASHER Ø12X24 MM |
|
25 |
13516921 |
STUD M8X12X22 MM |
|
26 |
16730024 |
STUD M8X55 |
|
29 |
8027280 |
CLIP |
