| Item |
Part number |
Description |
|
1 |
1907561 |
KIT-OILSUMP GASKET |
|
3 |
4767547 |
OIL SUMP ASSY |
|
4 |
16992311 |
LOCK PLUG M14X1,5 |
|
5 |
4858608 |
SEAL GASKET dia.14x19,5x1,5 |
|
6 |
4798806 |
COVER |
|
7 |
17037931 |
HEXAGON NUT M8X1,25 |
|
8 |
17095104 |
WASHER Ø10X21X2 MM |
|
9 |
10923621 |
HEXAGON BOLT M10X1,25X35 MM |
|
10 |
11343824 |
HEXAGON BOLT M10X1,25X50 MM |
|
11 |
16744621 |
STUD |
|
12 |
4852556 |
FLAT ENGINE GASKET |
|
13 |
15971824 |
SCREW M10X1,25X100 |
|
14 |
15970924 |
HEXAGON BOLT M10X1,25X35 MM |
|
15 |
11198371 |
SPRING WASHER Ø10X20 MM |
|
16 |
4798805 |
COVER |
|
17 |
4630672 |
FLAT ENGINE GASKET |
|
20 |
14308124 |
SCREW |
|
21 |
17095004 |
WASHER Ø10X18X2 MM |
