Item |
Part number |
Description |
1 |
4852556 |
FLAT ENGINE GASKET |
2 |
4697838 |
WATER PIPE |
3 |
98443290 |
PIPE SOCKET [from ...] |
4 |
4853970 |
FLAT ENGINE GASKET |
5 |
4762764 |
WATER PIPE [up to ...] |
6 |
4762766 |
WATER PIPE |
7 |
4859907 |
PIPE SOCKET [up to 657423] |
8 |
4859908 |
PIPE SOCKET [up to 657423] |
9 |
98431829 |
THERMOSTAT BODY ASSY [from 545610] |
10 |
98415712 |
PIPE SOCKET [from 657424] |
11 |
17288681 |
O-RING Ø24,9 MM SP=3,5 MM |
12 |
4851926 |
FLAT ENGINE GASKET |
13 |
4651371 |
SPACING BAR |
15 |
98401723 |
HEXAGON BOLT M8X1,25X12 MM |
16 |
8107873 |
WATER PIPE |
17 |
17742687 |
RUBBER SLEEVE |
18 |
10257060 |
SEAL GASKET Ø16X22 MM SP=1,5 MM |
19 |
16992440 |
THREADED PLUG M16X1,5 |
20 |
14496521 |
WASHER Ø8,5 MM |
21 |
17094914 |
WASHER 8x16 |
22 |
17090274 |
WASHER Ø10X20 MM |
23 |
98434883 |
WATER HOSE [up to ...] |
24 |
12077087 |
RUBBER SLEEVE |
25 |
12173790 |
CLIP Ø18-28 MM |
26 |
17764592 |
CLIP Ø20/32 MM |
28 |
98458442 |
O-RING Ø24,99 MM SP=3,53 MM [from 657424] |
29 |
15971721 |
SCREW M10X1,25X95 |
30 |
16043621 |
HEXAGON BOLT M8X25 MM |
31 |
98417182 |
FLAT ENGINE GASKET [up to 07-92] |
32 |
16625734 |
HEXAGON BOLT M8X35 |
34 |
16992411 |
THREADED PLUG M16X1,5 |
35 |
4858609 |
WASHER Ø16X22 MM SP=1,5 MM |
36 |
98418656 |
WATER PIPE [from ...] |
37 |
14325301 |
LOCK PLUG Ø22 MM |
38 |
14325201 |
LOCK PLUG |
39 |
4798845 |
SCREW |
40 |
4804633 |
THERMOSTAT BODY ASSY [up to 545609] |
41 |
4784798 |
PIPE SOCKET [up to ...] |
42 |
17282281 |
O-RING 2,62x23,47 |
43 |
10305171 |
PLUG M22X1,5 |
45 |
10263460 |
WASHER Ø22X28X1,5 MM |
47 |
16997411 |
THREADED PLUG M16X1,5 |
48 |
99434231 |
THREADED PLUG M10X1,25 |
