8061i05.00
A08020004/03 OVERSIZE PUSHER FAN - high position

Iveco/FPT OVERSIZE PUSHER FAN

Item Part number Description
1 15888721 HEXAGON BOLT M10X1,25X55 MM
2 15971421 HEXAGON BOLT M10X1,25X80 MM
3 15972021 HEXAGON BOLT M10X1,25X110 MM
4 10300771 LOCK PLUG M16X1,5
5 10278660 SEAL GASKET Ø16X22 MM SP=1 MM
6 10356011 C'SUNK SCREW M8X14 MM
7 4919302 COVER
8 4601884 FLAT ENGINE GASKET
9 10269650 LOCK PLUG
10 4626119 SUPPORT
11 4658663 FLAT ENGINE GASKET
12 4599561 FLAT ENGINE GASKET
13 4599562 FLAT ENGINE GASKET
14 4753433 WATER PIPE
15 4934627 RUBBER SLEEVE
16 12174090 HOSE CLIP Ø32-52 MM
17 8106572 WATER PIPE
18 8005264 WATER PIPE
19 10260160 SEAL GASKET Ø10X14 MM SP=1 MM
20 8102227 RETAINER
21 10440990 PIPE CLIP Ø45 MM
22 10902021 HEXAGON BOLT M6X12 MM
23 11197771 SPRING WASHER Ø6X12 MM SP=1,2 MM
24 11198371 SPRING WASHER Ø10X20 MM
