| Item |
Part number |
Description |
|
1 |
4746561 |
HOOK FRONT |
|
2 |
98439779 |
HOOK REAR RIGHT |
|
3 |
98439780 |
HOOK REAR LEFT |
|
4 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
5 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
6 |
16043224 |
SCREW M8X16 MM |
|
7 |
15970524 |
HEXAGON BOLT M10X1,25X20 |
|
8 |
16605924 |
SCREW M8X40 MM |
|
9 |
17037931 |
HEXAGON NUT M8X1,25 |
|
10 |
8107925 |
SUPPORT REAR |
|
11 |
8105558 |
ENGINE SUSPENSION FRONT - RIGHT |
|
12 |
8105550 |
ENGINE SUSPENSION LEFT |
|
13 |
4927434 |
SPACING BAR RIGHT |
|
14 |
16733224 |
STUD M12X1,75X30 |
|
15 |
17038421 |
HEXAGON NUT M12 (8) |
|
16 |
17091074 |
WASHER Ø12X24X2,8 MM |
|
17 |
15004021 |
HEXAGON BOLT M10X1,25X25 MM |
