| Item |
Part number |
Description |
|
1 |
8112607 |
INTAKE ELBOW ASSY |
|
2 |
4851921 |
INTAKE ELBOW GASK. |
|
3 |
8006416 |
INTAKE ELBOW |
|
4 |
8006418 |
HEAT EXCHANG.COVER |
|
5 |
8006421 |
O-RING |
|
6 |
8006419 |
TUBE STACK |
|
7 |
8006417 |
HEAT EXCHANG.COVER |
|
8 |
8006420 |
SPACING BAR |
|
9 |
8006683 |
SWITCH |
|
10 |
8105277 |
SACRIFICAL ANODE Ø14 MM |
|
11 |
4858607 |
WASHER Ø12X17 MM SP=1,5 MM |
|
12 |
4917793 |
PLUG M18 |
|
13 |
16992540 |
PLUG M18X1,5 |
|
14 |
4858610 |
WASHER Ø18X24 MM SP=1,5 MM |
|
15 |
4858606 |
GASKET Ø10X14X1 MM |
|
16 |
11903140 |
PLUG M10X1,25 |
|
17 |
16690824 |
CYLIND-HEAD SCREW M8X35 MM |
|
18 |
17800474 |
WASHER Ø8X15X1,0 MM |
|
19 |
17037931 |
HEXAGON NUT M8X1,25 |
|
20 |
16729424 |
STUD M8X1,25X25 |
|
21 |
16729624 |
STUD M8X35 |
|
22 |
8025610 |
PIPE SOCKET |
|
23 |
8017600 |
BALL Ø10 MM |
|
24 |
10305040 |
LOCK PLUG M20X1,5 |
|
25 |
98429280 |
SEAL GASKET Ø20X26 MM SP=1,5 MM |
|
26 |
16992240 |
THREADED PLUG M12X1,5 |
|
27 |
8025612 |
NUT |
|
28 |
8025611 |
SCREW M10X25 |
|
29 |
17094914 |
WASHER 8x16 |
