8061SRM33.40
3010.085/01 LUBE OIL LINES
Item | Part number | Description |
---|---|---|
1 | 98412645 | OIL LINE |
2 | 4864079 | SCREW CONNECTOR M10X1 |
3 | 4864080 | SCREW CONNECTOR M10X1,25 |
4 | 98474305 | WASHER Ø10X17 MM SP=2,3 |
5 | 4804122 | CLIP |
