8065E00.00A009
0710.153 INTAKE MANIFOLD

Iveco/FPT INTAKE MANIFOLD

Item Part number Description
1 4776966 INTAKE ELBOW
2 4851921 INTAKE ELBOW GASK.
3 4577310 THREADED PLUG
4 17037931 HEXAGON NUT M8X1,25
5 4936561 AIR MANIFOLD
6 10260160 SEAL GASKET Ø10X14 MM SP=1 MM
7 16997711 LOCK PLUG M22X1,5
8 17094914 WASHER 8x16
9 13543321 STUD M8X16X20 MM
10 13449521 STUD M10X15X25
11 16605624 HEXAGON BOLT M8X25 MM (8.8)
12 98400790 FLAT ENGINE GASKET
13 16605824 HEXAGON BOLT M8X35 MM
14 17090174 SPRING WASHER Ø10X20 MM
16 4753563 PLUG M10X1,5
17 13449824 STUD M10X1,25X15 MM
