8065SRE10.00
A01050020/03 OIL SUMP - max longitudinal inclination 45°
| Item | Part number | Description |
|---|---|---|
| 1 | 8023838 | OIL LINE |
| 2 | 16606624 | HEXAGON BOLT M8X80 MM |
| 3 | 98415923 | FLAT ENGINE GASKET |
| 4 | 4813599 | ELBOW COUPLING |
| 5 | 4600893 | GASKET |
| 6 | 4763804 | FASTENING BRACKET |
| 7 | 99444724 | TURBOCHARGER HOSE Ø22 MM L=55 MM |
| 8 | 16605424 | SCREW M8X16 MM (8.8) |
| 9 | 4858605 | WASHER Ø8X12 MM |
| 10 | 17089474 | SPRING WASHER Ø8X16 MM SP=1,4 MM |
| 11 | 8107409 | RETAINER |
| 12 | 17816214 | SPACER Ø10X8,5X18 MM |
| 13 | 16605524 | HEXAGON BOLT M8X20 MM |
| 14 | 17037931 | HEXAGON NUT M8X1,25 |
| 15 | 17764592 | CLIP Ø20/32 MM |
