Item |
Part number |
Description |
1 |
504020088 |
PROTECTION |
2 |
99456476 |
TIMING BELT |
3 |
504010962 |
COVER BOTTOM |
4 |
99447327 |
SPACER SP=5 MM [from 1832166] |
5 |
16288424 |
HEXAGON BOLT M10X1,25X25 MM |
6 |
17798374 |
SPRING WASHER Ø10,2X18,1 MM |
7 |
16605534 |
HEXAGON BOLT M8X20 MM (10.9) |
8 |
500324448 |
CAMSHAFT PINION |
9 |
500327941 |
SUPPORT |
10 |
500342834 |
HEXAGON BOLT M8X30 MM |
11 |
98479895 |
SPACING BAR [from 1832166] |
12 |
500326919 |
SPACER SP=8,3 MM |
13 |
12646721 |
WASHER Ø8X20 MM |
14 |
16592224 |
HEXAGON BOLT M8X55 MM |
15 |
2992485 |
ENGINE BEARINGS Ø25X67 MM SP=34 MM |
16 |
504022580 |
COVER |
17 |
4279745 |
BELT TENSIONER |
18 |
2992484 |
ENGINE BEARINGS |
19 |
17097124 |
WASHER 10x21 |
20 |
17038221 |
HEXAGON NUT M10 |
21 |
500326852 |
SUPPORT |
22 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
23 |
7300035 |
SPACER RIV-SKF |
24 |
99459430 |
INJ.PUMP DRIV.GEA |
25 |
500372179 |
LOCKING SCREW M12X1,25X30 MM |
26 |
504062798 |
FLAT ENGINE GASKET |
27 |
504065638 |
DOWEL PIN |
