| Item |
Part number |
Description |
|
1 |
4827093 |
SUPPORT |
|
2 |
4827098 |
BELT TENSIONER |
|
3 |
4827099 |
RETAINER |
|
4 |
99435705 |
AIR COND.COMPRESS. ASSY KNORR |
|
5 |
500337152 |
V-BELT L=850 MM |
|
7 |
17091174 |
SPRING WASHER Ø12X24 MM |
|
8 |
7300998 |
SPACING BAR |
|
9 |
7301000 |
RUBBER BUSH |
|
10 |
7300999 |
SPACING BAR |
|
11 |
7301766 |
SCREW |
|
12 |
7301767 |
STOP PLATE |
|
13 |
7301772 |
SPACING BAR |
|
14 |
15970921 |
HEXAGON BOLT M10X1,25X35 MM |
|
15 |
4827101 |
RETAINER |
|
16 |
11288024 |
HEXAGON BOLT M10X1,25X60 MM |
|
17 |
17153021 |
HEXAGON NUT M10X1,25 |
|
18 |
15543221 |
HEXAGON BOLT M12X1,25X125 MM |
|
19 |
15888824 |
HEXAGON BOLT M10X1,25X70 MM |
|
20 |
17038221 |
HEXAGON NUT M10 |
|
21 |
17038621 |
NUT M12 |
|
22 |
17090274 |
WASHER Ø10X20 MM |
|
23 |
99466601 |
AIR COND.COMPRESS. [from ...] |
