| Item |
Part number |
Description |
|
1 |
8007544 |
OIL SUMP ASSY |
|
2 |
99488483 |
OIL SUMP GASKET |
|
3 |
7300542 |
SUCTION STRAINER |
|
4 |
8016591 |
OIL DIPSTICK |
|
5 |
8039908 |
OIL LEVEL TUBE |
|
7 |
8031803 |
FASTENING BRACKET |
|
8 |
16992611 |
THREADED PLUG M22X1,5 |
|
9 |
10263460 |
WASHER Ø22X28X1,5 MM |
|
10 |
17316690 |
FASTENING BRACKET Ø20,5 MM |
|
12 |
17282221 |
O-RING |
|
13 |
17277981 |
O-RING 1,78x9,25 |
|
16 |
16605524 |
HEXAGON BOLT M8X20 MM |
|
17 |
17152821 |
NUT M8 [up to 555939] |
|
18 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
19 |
17094914 |
WASHER 8x16 |
|
20 |
16605424 |
SCREW M8X16 MM (8.8) |
|
21 |
17044721 |
HEXAGON NUT M8X1,25 |
|
22 |
8025264 |
STUD |
|
23 |
8019206 |
OIL LINE |
|
24 |
500368999 |
RUBBER SLEEVE |
|
25 |
11903211 |
LOCK PLUG M12X1,25 |
|
26 |
4858607 |
WASHER Ø12X17 MM SP=1,5 MM |
|
27 |
8019884 |
RETAINER |
|
28 |
18088391 |
CLIP Ø16/25 MM |
|
29 |
18088491 |
CLIP |
