8141i07.01
0710.028 INTAKE MANIFOLD
| Item | Part number | Description |
|---|---|---|
| 1 | 4813756 | INTAKE ELBOW |
| 2 | 98425767 | INTAKE ELBOW GASK. SP=0,8 MM |
| 3 | 10257260 | SEAL GASKET SP=0,5 MM |
| 4 | 10304911 | THREADED PLUG M20X1,5 |
| 5 | 12654421 | WASHER SP=3 MM |
| 6 | 17037931 | HEXAGON NUT M8X1,25 |
| 7 | 13543221 | STUD M8X16X18 MM |
| 8 | 13543521 | STUD M8X16X25 MM |
