8210Si15.00
A28010048/02 ELECTRONIC GOVERNOR WOODWARD - 24V [D 07-1994] [from07-1994]

Iveco/FPT ELECTRONIC GOVERNOR WOODWARD

Item Part number Description
1 16992411 THREADED PLUG M16X1,5
2 4858609 WASHER Ø16X22 MM SP=1,5 MM
3 10717311 NUT M12
4 17088974 SPRING WASHER Ø6X18X1,4 MM
5 4934404 SCREW
6 14309221 SCREW M6X65
7 16689134 SOCKET-HEAD SCREW M6X16 MM
8 8007450 TIMINGGEAR HOUSIN
9 8108716 NUT
10 8015485 GASKET
11 4858607 WASHER Ø12X17 MM SP=1,5 MM
12 10300571 PLUG M12X1,5
13 14158570 DOWEL PIN Ø2,3 MM
14 8009910 GASKET
15 8108601 LEVER
16 8007452 COVER ASSY
17 8108604 PIN
18 17094714 WASHER Ø6,4X12 MM
19 17152621 NUT M5X0,8
20 8109360 SCREW M5X12
21 8109731 PIN
22 8109732 WASHER
23 12574011 NUT M4
24 17037721 NUT M5X0,8
25 8108715 SCREW
26 17130714 SCREW
27 8019000 FUEL LINE
28 8018344 FUEL LINE [from 07-94]
29 8016443 FUEL LINE
30 61608319 SCREW CONNECTOR
31 17281581 O-RING Ø12,37X2,62 MM
32 8006339 CAP
33 16508711 NUT M14X1,5 [from 05-92]
34 98474308 SEAL GASKET Ø14X22 MM
35 4864083 SCREW CONNECTOR M14X1,5X30 MM
36 8017500 ELECTROVALVE [from 04-94]
37 8102465 VALVE
38 8020609 SCREW CONNECTOR [from 04-94]
39 79010214 PIPE SOCKET 1C
40 8012017 INLINE INJECT.PUMP ASSY BOSCH
41 8010505 CLAMP Ø16 MM
42 16605924 SCREW M8X40 MM
43 17094914 WASHER 8x16
44 17152821 NUT M8 [up to 555939]
45 4858608 SEAL GASKET dia.14x19,5x1,5
