| Item |
Part number |
Description |
|
1 |
8025474 |
WATER PIPE |
|
2 |
8024718 |
WATER PIPE |
|
3 |
17290281 |
O-RING Ø63,09 MM SP=3,53 MM |
|
4 |
16587124 |
HEXAGON BOLT M10X25 MM |
|
5 |
8024719 |
WATER PIPE |
|
6 |
8024720 |
WATER PIPE |
|
7 |
17289981 |
O-RING Ø53,57X3,53 MM |
|
8 |
16609824 |
HEXAGON BOLT M12X1,75X25 MM |
|
9 |
17091074 |
WASHER Ø12X24X2,8 MM |
|
10 |
8010366 |
WATER HOSE |
|
11 |
17764993 |
CLIP Ø50/70 MM |
|
12 |
4865234 |
RUBBER SLEEVE |
|
13 |
8024721 |
WATER PIPE |
|
14 |
17290481 |
O-RING 3,53x69,44 [UP TO # 328594] |
|
15 |
8024722 |
WATER PIPE |
|
16 |
17068121 |
NUT M10 |
|
18 |
16690624 |
CYLIND-HEAD SCREW M8X25 MM |
|
19 |
17101534 |
SPRING WASHER Ø8 MM |
|
20 |
16992240 |
THREADED PLUG M12X1,5 |
|
21 |
4858607 |
WASHER Ø12X17 MM SP=1,5 MM |
|
22 |
8113295 |
CLAMP Ø50 MM |
|
23 |
8113296 |
CLAMP Ø50 MM |
|
24 |
1366290 |
RUBBER LUG |
|
25 |
16605524 |
HEXAGON BOLT M8X20 MM |
|
26 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
27 |
17037931 |
HEXAGON NUT M8X1,25 |
|
28 |
8007133 |
RETAINER |
|
29 |
8025372 |
RETAINER |
|
30 |
8111685 |
RETAINER |
|
31 |
16608824 |
HEXAGON BOLT M10X100 MM |
|
32 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
33 |
12626201 |
WASHER Ø10,25X3 MM |
