| Item |
Part number |
Description |
|
1 |
99466903 |
CYLINDER HEAD ASSY |
|
2 |
13449930 |
STUD M10X40 MM |
|
3 |
4648237 |
VALVE GUIDE |
|
4 |
4630923 |
VALVE GUIDE |
|
5 |
98444350 |
VALVE SEAT STD. GOETZE |
|
6 |
98444352 |
VALVE SEAT +0.20 GOETZE |
|
7 |
98444351 |
VALVE SEAT +0.05 GOETZE |
|
8 |
4673864 |
VALVE SEAT STD. |
|
9 |
4673868 |
VALVE SEAT +0.20 |
|
10 |
4673869 |
VALVE SEAT +0.05 |
|
11 |
4817147 |
NOZZLE HOLDER SEAT |
|
12 |
4638192 |
PIPE |
|
13 |
4623879 |
PIPE |
|
14 |
61584412 |
LOCK PLUG |
|
15 |
16991070 |
LOCK PLUG Ø32 MM |
|
16 |
98480127 |
HEAD COVER GASKET [from 08-97] |
|
17 |
4769616 |
CYL.HEAD STUD |
|
18 |
98474544 |
CYL. HEAD COVER |
|
19 |
99465715 |
CYL.HEAD GASKET |
|
20 |
4769615 |
SCREW |
|
21 |
16606424 |
HEXAGON BOLT M8X65 MM |
|
22 |
17094914 |
WASHER 8x16 |
|
23 |
17278981 |
O-RING Ø25,12 MM SP=1,78 MM |
|
24 |
98460467 |
CYL.HEAD GASKET [up to 456043] |
