| Item |
Part number |
Description |
|
1 |
500301260 |
SET OF V-BELTS KIT |
|
2 |
98484127 |
SUPPORT |
|
3 |
99448868 |
PULLEY Ø126 MM |
|
4 |
16874776 |
CIRCLIP Ø85,5 MM [from 10-92] |
|
5 |
98427607 |
ENGINE BEARINGS |
|
6 |
98427590 |
WASHER |
|
7 |
17091071 |
SPRING WASHER Ø12X24 SP=2,8 MM |
|
8 |
15541421 |
HEXAGON BOLT M12X1,25X80 MM |
|
9 |
10790111 |
HEXAGON NUT M10X1,25 |
|
10 |
99448867 |
BELT TENSIONER ASSY |
|
11 |
12646921 |
WASHER Ø12X28 MM |
|
12 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
13 |
17038621 |
NUT M12 |
|
17 |
15540521 |
SCREW M12X1,25X35 |
|
18 |
98499903 |
PULLEY [up to 440071] |
|
19 |
500301088 |
BELT TENSIONER ASSY [up to 440071] |
|
20 |
11197974 |
WASHER Ø12 MM |
