| Item |
Part number |
Description |
|
1 |
99440226 |
AIR COMPRESSOR ASSY BENDIX |
|
2 |
8012904 |
PLUG |
|
3 |
4710288 |
FLAT ENGINE GASKET |
|
4 |
4710274 |
COMP. DRIVE GEAR |
|
5 |
4709364 |
LOCKING PLATE |
|
6 |
99471892 |
HEXAGON NUT |
|
7 |
4723050 |
LINE |
|
8 |
4513714 |
GASKET |
|
9 |
8114247 |
AIR PIPE/DUCT |
|
10 |
4787287 |
WATER HOSE |
|
11 |
98450706 |
WATER PIPE |
|
12 |
11234721 |
HEXAGON BOLT M10X1,25X45 MM |
|
13 |
4858609 |
WASHER Ø16X22 MM SP=1,5 MM |
|
14 |
4864084 |
BANJO BOLT M16X1,5 |
|
15 |
11194079 |
SPRING WASHER Ø8X16 MM SP=1,9 MM |
|
16 |
12173690 |
CLIP Ø14-22 MM |
|
17 |
15001324 |
HEXAGON BOLT M8X45 MM |
|
18 |
15000824 |
HEXAGON BOLT M8X25 MM |
|
19 |
13953721 |
STUD M10X15X115 |
|
20 |
98434330 |
HEXAGON BOLT |
|
21 |
4864028 |
FLAT ENGINE GASKET |
|
22 |
11198379 |
SPRING WASHER Ø10X20 MM SP=2,6 |
|
23 |
12164711 |
HEXAGON NUT M10X1,25 |
|
24 |
5120406 |
HYDRAULIC PUMP ASSY |
|
25 |
4503785 |
WASHER |
|
26 |
568170 |
O-RING |
|
27 |
4850986 |
FLAT ENGINE GASKET |
|
28 |
14305521 |
SCREW M6X30 |
|
29 |
4670953 |
PIPE SOCKET |
|
30 |
4690715 |
PIPE SOCKET |
|
31 |
14306621 |
SCREW M8X35 |
|
32 |
8090343 |
KIT-HYDRAULIC PUMP |
|
33 |
10980821 |
STUD M6X15X30 MM |
|
34 |
11198079 |
SPRING WASHER Ø8,2 MM |
|
35 |
11197779 |
SPRING WASHER Ø6X12 MM |
|
36 |
15896211 |
HEXAGON NUT M6 |
|
37 |
8114264 |
RETAINER |
|
38 |
4760226 |
FASTENING BRACKET |
|
39 |
11193879 |
SPRING WASHER Ø8X16 MM |
|
40 |
16043221 |
HEXAGON BOLT M8X16 MM |
|
42 |
11190679 |
SPRING WASHER Ø10X27 MM SP=2,5 |
|
43 |
12176990 |
CLIP Ø24-36 MM |
|
44 |
4605529 |
RUBBER SLEEVE |
|
45 |
8114248 |
AIR PIPE/DUCT |
|
46 |
4724973 |
RUBBER SLEEVE |
|
47 |
4734507 |
THREADED UNION |
