| Item |
Part number |
Description |
|
1 |
4863965 |
FLAT ENGINE GASKET |
|
2 |
4863967 |
FLAT ENGINE GASKET |
|
3 |
4621091 |
CLIP |
|
4 |
4745272 |
THREADED UNION |
|
5 |
4682418 |
THREADED UNION |
|
6 |
4778438 |
RUBBER SLEEVE WATER |
|
7 |
8100819 |
RETAINER |
|
8 |
8109179 |
OIL LINE ASSY |
|
9 |
8109180 |
OIL LINE |
|
10 |
8109234 |
OIL LINE |
|
11 |
98429224 |
SCREW CONNECTOR |
|
12 |
98429280 |
SEAL GASKET Ø20X26 MM SP=1,5 MM |
|
13 |
4858608 |
SEAL GASKET dia.14x19,5x1,5 |
|
14 |
10296260 |
SEAL GASKET Ø28X36 MM SP=1,5 MM |
|
15 |
10300611 |
LOCK PLUG M14X1,5 |
|
16 |
11106421 |
HEXAGON BOLT M10X1,5X30 MM |
|
17 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
19 |
17764693 |
CLIP Ø25/40 MM |
|
20 |
10450490 |
PIPE CLIP Ø16 MM |
|
21 |
14420421 |
SCREW M10X1,5X40 |
|
22 |
16043021 |
HEXAGON BOLT M8X12 MM |
|
23 |
17037931 |
HEXAGON NUT M8X1,25 |
|
24 |
16507011 |
NUT M22X1,5 |
|
25 |
16507711 |
WASHER Ø15 MM |
|
26 |
17090174 |
SPRING WASHER Ø10X20 MM |
