| Item |
Part number |
Description |
|
1 |
8110635 |
WATER PIPE |
|
2 |
8102754 |
GASKET |
|
3 |
8102752 |
SPACING BAR |
|
4 |
4918857 |
GASKET |
|
5 |
8108931 |
WATER PIPE |
|
6 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
7 |
17037931 |
HEXAGON NUT M8X1,25 |
|
8 |
98428450 |
WATER PIPE |
|
14 |
11194079 |
SPRING WASHER Ø8X16 MM SP=1,9 MM |
|
15 |
12177290 |
CLIP Ø62-82 MM |
|
16 |
8107383 |
RUBBER SLEEVE Ø60 MM |
|
17 |
15970521 |
HEXAGON BOLT M10X20 MM |
|
18 |
8110973 |
RETAINER |
|
19 |
10296160 |
SEAL GASKET Ø12X18 MM SP=1 MM |
|
20 |
10300511 |
LOCK PLUG M12X1,5 |
|
21 |
4568427 |
RUBBER PAD |
|
22 |
4936328 |
CLIP ASSY |
|
23 |
17764993 |
CLIP Ø50/70 MM |
|
24 |
8110206 |
WATER HOSE |
|
25 |
8110207 |
WATER HOSE |
|
26 |
4547637 |
FLAT ENGINE GASKET |
|
27 |
11198379 |
SPRING WASHER Ø10X20 MM SP=2,6 |
|
28 |
16043621 |
HEXAGON BOLT M8X25 MM |
|
29 |
4709713 |
WATER PIPE |
|
30 |
11198079 |
SPRING WASHER Ø8,2 MM |
