8281I03.00A803
0710.036 INTAKE MANIFOLD

Iveco/FPT INTAKE MANIFOLD

Item Part number Description
1 4687152 INTAKE ELBOW
2 4762475 INTAKE ELBOW LEFT
3 1905531 FLAT ENGINE GASKET
4 4690534 COVER
5 4863536 FLAT ENGINE GASKET
6 1904876 INTAKE ELBOW GASK.
7 1904875 INTAKE ELBOW GASK.
8 4701030 INTAKE ELBOW
9 4577310 THREADED PLUG
10 16508460 WASHER 22x27x1,5
11 16997411 THREADED PLUG M16X1,5
12 17089974 SPRING WASHER Ø8X22X2,4MM
13 16043821 HEXAGON BOLT M8X30 MM
14 16044921 HEXAGON BOLT M8X1,25X85 MM
15 15971821 SCREW M10X1,25X100
16 11198474 SPRING WASHER Ø10X27 MM
17 15970921 HEXAGON BOLT M10X1,25X35 MM
18 15972221 SCREW M10X1,25X120
19 13516721 STUD M8X12X18 MM
20 16043321 HEXAGON BOLT M8X18 MM
21 17089474 SPRING WASHER Ø8X16 MM SP=1,4 MM
