8281M32.10
A01060002/02 OIL SUMP OVERSIZE - max longitudinal inclination 16°
| Item | Part number | Description |
|---|---|---|
| 1 | 4673579 | SUCTION STRAINER TOP |
| 2 | 4863505 | FLAT ENGINE GASKET |
| 3 | 4863533 | FLAT ENGINE GASKET |
| 4 | 4710049 | OIL FILTER COVER |
| 5 | 4673581 | FILTER |
| 6 | 4673582 | FASTENING RING |
| 7 | 17089574 | WASHER Ø8X16 MM |
| 8 | 16625734 | HEXAGON BOLT M8X35 |
| 9 | 17089974 | SPRING WASHER Ø8X22X2,4MM |
| 10 | 16044121 | HEXAGON BOLT M8X45 MM (8.8) |
| 11 | 16043424 | HEXAGON BOLT M8X20 MM |
