| Item |
Part number |
Description |
|
1 |
4797319 |
HAND PUMP ASSY |
|
2 |
4570827 |
PIPE SOCKET |
|
3 |
98474308 |
SEAL GASKET Ø14X22 MM |
|
4 |
16603824 |
SCREW M6X25 |
|
5 |
11351379 |
PLATE |
|
6 |
4864083 |
SCREW CONNECTOR M14X1,5X30 MM |
|
7 |
8112071 |
FUEL LINE |
|
8 |
16507511 |
WASHER |
|
9 |
8112074 |
FUEL LINE |
|
10 |
8112969 |
PIPE SOCKET |
|
11 |
8113294 |
RETAINER |
|
12 |
8112970 |
PIPE SOCKET |
|
13 |
16501611 |
PIPE SOCKET M14X1,5 |
|
14 |
16508811 |
NUT M16X1,5 |
|
15 |
8112076 |
INJECTION LINE |
|
16 |
8112075 |
INJECTION LINE |
|
17 |
8024645 |
O-RING Ø4 MM |
|
23 |
8008219 |
RETAINER |
|
24 |
15540321 |
HEXAGON BOLT M12X1,25X25 MM |
|
25 |
17091071 |
SPRING WASHER Ø12X24 SP=2,8 MM |
