8281SRM70.12
0710.121 INTAKE MANIFOLD

Iveco/FPT INTAKE MANIFOLD

Item Part number Description
1 8026382 INTAKE ELBOW
2 4786886 GASKET
3 4789747 INTAKE ELBOW GASK.
4 4718509 COVER
6 4746828 COVER
7 4742337 COVER
8 500301317 GASKET
10 16992511 THREADED PLUG M18X1,5
11 8104267 SPACING BAR
12 4858610 WASHER Ø18X24 MM SP=1,5 MM
13 17038221 HEXAGON NUT M10
14 17090174 SPRING WASHER Ø10X20 MM
15 16992211 THREADED PLUG M12X1,5
16 4858607 WASHER Ø12X17 MM SP=1,5 MM
17 4667393 STUD M10X1,5/M10X1,25
18 17090474 SPRING WASHER Ø10X27 MM SP=2,5
19 17089574 WASHER Ø8X16 MM
20 17095101 WASHER Ø10X18 MM
22 13546521 STUD M10X1,25X20X30 MM
23 11306921 SCREW M10X1,25X30
24 16729324 STUD M8X12X20 MM
25 17037931 HEXAGON NUT M8X1,25
26 15970921 HEXAGON BOLT M10X1,25X35 MM
27 4720250 SCREW
28 4742340 PLUG
29 4742339 PIPE SOCKET
30 10263460 WASHER Ø22X28X1,5 MM
