| Item |
Part number |
Description |
|
1 |
8009167 |
INTAKE ELBOW LEFT |
|
2 |
8009166 |
INTAKE ELBOW RIGHT |
|
3 |
8105950 |
FLANGE |
|
4 |
8105952 |
PLATE |
|
5 |
17291281 |
O-RING Ø94,84 MM SP=3,53 MM |
|
6 |
8105951 |
CIRCLIP |
|
7 |
8006821 |
RUBBER SLEEVE |
|
8 |
17290781 |
O-RING Ø78,97X3,53 MM |
|
9 |
17285281 |
O-RING Ø71,12 MM SP=2,62 MM |
|
10 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
11 |
16605924 |
SCREW M8X40 MM |
|
12 |
16606024 |
SCREW M8X45 MM |
|
13 |
8009119 |
INTAKE ELBOW ASSY |
|
14 |
17873271 |
THREADED INSERT M8 |
|
15 |
8006824 |
PIPE SOCKET |
|
16 |
8011504 |
SPACING BAR |
|
17 |
8011353 |
RETAINER |
|
18 |
17282381 |
O-RING Ø25,07 MM SP=2,62 MM |
|
19 |
16605524 |
HEXAGON BOLT M8X20 MM |
