8291SRM75.10
2710.013 OIL DIPSTICK
| Item | Part number | Description |
|---|---|---|
| 1 | 8009280 | OIL FILLER PIPE |
| 2 | 4882530 | STRAINER |
| 3 | 17290581 | O-RING Ø72,63X3,53 MM |
| 4 | 4882777 | PLUG |
| 5 | 4854896 | O-RING |
| 6 | 8009320 | OIL DIPSTICK |
| 7 | 8009319 | OIL LEVEL TUBE |
| 8 | 4882591 | CHAIN |
| 9 | 16865076 | CIRCLIP |
| 10 | 17095104 | WASHER Ø10X21X2 MM |
| 12 | 17089474 | SPRING WASHER Ø8X16 MM SP=1,4 MM |
| 13 | 17037931 | HEXAGON NUT M8X1,25 |
| 14 | 17239320 | PIN |
| 15 | 16747024 | STUD |
| 16 | 16865776 | CIRCLIP Ø15,7 MM |
| 17 | 17095704 | WASHER Ø16X30 MM |
| 18 | 17296081 | O-RING Ø56,52X5,33 MM |
| 19 | 4882506 | COVER |
| 20 | 4854897 | O-RING |
| 21 | 4882529 | ROD |
| 22 | 16605624 | HEXAGON BOLT M8X25 MM (8.8) |
| 23 | 11270660 | SEAL GASKET Ø20X24 MM |
