Item |
Part number |
Description |
1 |
99443894 |
AIR PIPE/DUCT [from 280959] |
2 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
3 |
99443185 |
RETAINER BUNDY [from 280959] |
4 |
99443574 |
AIR PIPE/DUCT |
5 |
98412812 |
AIR PIPE/DUCT [up to 280958] |
6 |
4853259 |
AIR PIPE/DUCT |
7 |
4853260 |
CLIP |
8 |
4853264 |
CLIP |
9 |
17283981 |
O-RING Ø50,4 MM SP=2,6 MM |
10 |
17285481 |
O-RING Ø75,87 MM SP=2,62 MM |
11 |
4862201 |
RETAINER [up to 280958] |
12 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
14 |
12646901 |
WASHER Ø12X28 MM |
15 |
15970321 |
HEXAGON BOLT M10X16 MM |
16 |
17090174 |
SPRING WASHER Ø10X20 MM |
17 |
98411795 |
FASTENING BRACKET |
18 |
17090074 |
SPRING WASHER Ø10X20X1,9 MM |
19 |
15970521 |
HEXAGON BOLT M10X20 MM |
20 |
98411638 |
AIR PIPE/DUCT |
21 |
17037931 |
HEXAGON NUT M8X1,25 |
22 |
4853268 |
FLAT ENGINE GASKET |
23 |
13543524 |
STUD M8X16X25 |
