| Item |
Part number |
Description |
|
1 |
4934984 |
PLUG |
|
2 |
8009696 |
SCREW CONNECTOR M12X1,5X25 |
|
3 |
98432897 |
WATER HOSE |
|
4 |
98412396 |
GASKET |
|
5 |
4936216 |
WATER PIPE |
|
6 |
10304911 |
THREADED PLUG M20X1,5 |
|
7 |
98412227 |
GASKET |
|
8 |
4726340 |
WATER PIPE |
|
9 |
98412317 |
GASKET |
|
10 |
8012512 |
WATER PIPE |
|
11 |
8106109 |
WATER PIPE |
|
12 |
8107512 |
WATER PIPE |
|
13 |
8106102 |
WATER PIPE |
|
14 |
8106101 |
WATER PIPE |
|
15 |
10265160 |
SEAL GASKET Ø35,3 MM |
|
16 |
98474306 |
WASHER Ø12X20 MM SP=1,9 MM |
|
17 |
8113358 |
PIPE SOCKET |
|
18 |
4858607 |
WASHER Ø12X17 MM SP=1,5 MM |
|
19 |
16992240 |
THREADED PLUG M12X1,5 |
|
20 |
4927760 |
PIPE SOCKET M22X1,5 |
|
21 |
10263460 |
WASHER Ø22X28X1,5 MM |
|
22 |
10257460 |
SEAL GASKET Ø20X26 MM SP=1,5 MM [up to ...] |
|
23 |
16100821 |
HEXAGON NUT M8 |
|
24 |
8012513 |
WATER PIPE |
|
26 |
17743887 |
RUBBER SLEEVE |
|
27 |
4864082 |
BANJO BOLT M12X1,5X25 MM |
|
28 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
29 |
17090274 |
WASHER Ø10X20 MM |
|
30 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
31 |
98490783 |
CLIP Ø55-65 MM |
|
32 |
13517021 |
STUD M8X25 MM |
|
33 |
15970521 |
HEXAGON BOLT M10X20 MM |
|
34 |
16045721 |
HEXAGON BOLT M8X125 MM |
|
35 |
16043621 |
HEXAGON BOLT M8X25 MM |
|
36 |
15004021 |
HEXAGON BOLT M10X1,25X25 MM |
|
38 |
16043321 |
HEXAGON BOLT M8X18 MM |
|
39 |
16992311 |
LOCK PLUG M14X1,5 |
|
40 |
4858608 |
SEAL GASKET dia.14x19,5x1,5 |
