8361SRE11.00
3280.010 WATER FILTER
| Item | Part number | Description |
|---|---|---|
| 1 | 1901776 | WATER FILTER CARTRIDGE |
| 2 | 4807728 | FILTER SUPPORT |
| 3 | 4807730 | BREATHER CONN. |
| 4 | 16605624 | HEXAGON BOLT M8X25 MM (8.8) |
| 5 | 17094914 | WASHER 8x16 |
| 6 | 98465103 | O-RING Ø21,8 MM SP=2,6 MM |
| 7 | 98474308 | SEAL GASKET Ø14X22 MM |
| 8 | 4864083 | SCREW CONNECTOR M14X1,5X30 MM |
| 9 | 98424255 | WATER PIPE |
| 10 | 4853516 | FILTER SUPPORT |
| 11 | 98465110 | O-RING Ø31,42 MM SP=2,62 MM |
| 12 | 17090174 | SPRING WASHER Ø10X20 MM |
| 13 | 11234724 | HEXAGON BOLT M10X1,25X45 MM |
