8361SRI12.00A800
0710.050 INTAKE MANIFOLD
| Item | Part number | Description |
|---|---|---|
| 1 | 8019997 | HEAT EXANGER BODY ASSY |
| 2 | 8026489 | TUBE STACK |
| 3 | 8017117 | COVER |
| 4 | 8017118 | HEAT EXCHANG.COVER |
| 5 | 17291981 | O-RING Ø117,07X3,53 MM |
| 6 | 8104374 | GASKET |
| 7 | 10304911 | THREADED PLUG M20X1,5 |
| 8 | 17800474 | WASHER Ø8X15X1,0 MM |
| 9 | 16690824 | CYLIND-HEAD SCREW M8X35 MM |
| 10 | 4851904 | INTAKE ELBOW GASK. |
| 11 | 98480270 | GASKET |
| 12 | 8025610 | PIPE SOCKET |
| 13 | 8017600 | BALL Ø10 MM |
| 14 | 13450021 | STUD |
| 15 | 13449721 | STUD M10X15X30 |
| 16 | 13450121 | STUD M10X15X50 |
| 17 | 17038221 | HEXAGON NUT M10 |
| 18 | 17090174 | SPRING WASHER Ø10X20 MM |
| 19 | 4858606 | GASKET Ø10X14X1 MM |
| 20 | 11903140 | PLUG M10X1,25 |
| 21 | 16992511 | THREADED PLUG M18X1,5 |
| 22 | 4858610 | WASHER Ø18X24 MM SP=1,5 MM |
| 23 | 16992111 | THREADED PLUG M10X1 |
| 24 | 8025612 | NUT |
| 25 | 8025611 | SCREW M10X25 |
