8361SRM40.10
0710.057 INTAKE MANIFOLD
| Item | Part number | Description |
|---|---|---|
| 1 | 8017598 | INTAKE ELBOW |
| 2 | 8104371 | TUBE STACK |
| 3 | 8017601 | HEAT EXCHANG.COVER |
| 4 | 8017603 | COVER |
| 5 | 17291981 | O-RING Ø117,07X3,53 MM |
| 6 | 8104374 | GASKET |
| 7 | 16729824 | STUD M8X45 MM |
| 8 | 17800474 | WASHER Ø8X15X1,0 MM |
| 9 | 16690824 | CYLIND-HEAD SCREW M8X35 MM |
| 10 | 8017267 | INTAKE ELBOW GASK. |
| 11 | 4858610 | WASHER Ø18X24 MM SP=1,5 MM |
| 12 | 8017599 | PLUG |
| 13 | 8017600 | BALL Ø10 MM |
| 14 | 13449721 | STUD M10X15X30 |
| 15 | 13530521 | STUD WAHLER |
| 16 | 13530621 | STUD M12X18X55 |
| 17 | 17038621 | NUT M12 |
| 18 | 17091074 | WASHER Ø12X24X2,8 MM |
| 19 | 8105277 | SACRIFICAL ANODE Ø14 MM |
| 20 | 4917793 | PLUG M18 |
| 21 | 16992540 | PLUG M18X1,5 |
