Item |
Part number |
Description |
1 |
8017609 |
BREATHER |
2 |
8009901 |
GASKET |
3 |
8823136 |
LOCK PLUG |
4 |
4858569 |
BREATHER |
5 |
4860370 |
SUPPORT [up to 03-97] |
6 |
16605734 |
HEXAGON BOLT M8X30 MM |
7 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
8 |
17037931 |
HEXAGON NUT M8X1,25 |
9 |
8018828 |
SUPPORT |
10 |
16605524 |
HEXAGON BOLT M8X20 MM |
11 |
8017326 |
BREATHER PIPE |
12 |
8015523 |
RUBBER SLEEVE Ø30 - Ø25 MM |
13 |
17764693 |
CLIP Ø25/40 MM |
14 |
17764793 |
CLIP Ø32/50 MM |
15 |
8105610 |
RUBBER SLEEVE |
16 |
18088392 |
CLIP Ø16/25 MM |
17 |
8017328 |
PIPE SOCKET |
18 |
4858610 |
WASHER Ø18X24 MM SP=1,5 MM |
19 |
16746724 |
STUD M8X25 MM |
20 |
4760226 |
FASTENING BRACKET |
21 |
8018468 |
OIL HOSE |
22 |
4929652 |
RETAINER |
