8460SRC21.20A002
3830.017 AIR COMPRESSOR (COMPONENTS)

Iveco/FPT AIR COMPRESSOR (COMPONENTS)

Item Part number Description
1 9918517 HALF-BEARING
2 93161233 KIT-AIR COMPRESSOR Ø80,5MM
3 93159475 FLANGE
4 79069742 KIT-AIR COMPRESSOR
5 79071642 KIT-AIR COMPRESSOR
6 93161231 KIT-AIR COMPRESSOR Ø80,2MM
7 93161232 KIT-AIR COMPRESSOR Ø80 MM
9 8199051 COVER BOTTOM
10 93161584 KIT-AIR COMPRESSOR
11 93161598 KIT-AIR COMPRESSOR
12 93161594 KIT-AIR COMPRESSOR
15 79098371 BUSH
16 79098372 RING
17 8124091 COMPR.CRANKSHAFT
18 9934284 KIT-AIR COMPRESSOR Ø80 MM
19 79098369 KIT-AIR COMPRESSOR
20 93161306 KIT-AIR COMPRESSOR Ø80,2MM
21 93161305 KIT-AIR COMPRESSOR Ø80 MM
22 93161307 KIT-AIR COMPRESSOR Ø80,5MM
23 79098370 KIT-AIR COMPRESSOR
24 93190969 COMPRESS.CONN.ROD ASSY
