C13ENAM19.00
2210.067 AIR CLEANER
| Item | Part number | Description |
|---|---|---|
| 1 | 98437331 | RUBBER SLEEVE |
| 2 | 8043790 | BREATHER PIPE |
| 3 | 8043703 | AIR CLEANER |
| 4 | 8033225 | CLIP |
| 5 | 8016336 | OIL HOSE |
| 6 | 4856492 | THREADED UNION |
| 7 | 4747140 | RUBBER PAD |
| 8 | 17816614 | SPACING BAR Ø8,5X18 MM SP=30 MM |
| 9 | 17090274 | WASHER Ø10X20 MM |
| 10 | 17089474 | SPRING WASHER Ø8X16 MM SP=1,4 MM |
| 11 | 16607524 | HEXAGON BOLT M10X1,5X20 MM (8.8) |
| 12 | 16606024 | SCREW M8X45 MM |
| 13 | 16605524 | HEXAGON BOLT M8X20 MM |
